PDFill PDF Filler: Insert PDF  Page like Image to Overlay

(See Example PDF and Example PDFill Project File  )

You can use this tool to insert a selected PDF Page into PDF document anywhere. You can add Rotation, Frame Lines, Whiteout (fill color or background) and PDF Action into this PDF Page object.

This PDF Overlay function lets you easily insert a new PDF Page with a company logo or other fixed item to every page of PDF files you create.

It also lets you place artwork or other fixed items onto just the first page of your PDF files, together with items that change from file to file.

Batch (DOS) Command Support: You can start a batch job in Windows by issuing the execution command directly from the MS-DOS command prompt window without opening the PDFill GUI.

1. Steps on how to insert PDF Page into Current PDF Document:

• Choose Menu Insert > Select Image or PDF Page

or check Image Or PDF Page button to insert a new PDF Page from the Format Toolbar.

• Hold and drag the left mouse button to draw the rectangle area for the new object area.

• To move the image, Move the cursor to the shadow area to see the Move icon to come up, then, drag the left mouse button to move the current object. Or, after you click the edge shadow area, move the Left, Right, Up and Down arrows. To rotate the PDF Page object,  hold the rotation bar and drag the mouse to rotate.
• To Align the objects, Edit Menu > Align Tools or Select Align Tools from Forms or Main Tool Bar:

• To Duplicate the PDF Page Object, right click the menu:

2. Access the properties:

• Click the Selection button first.
• Click inside the line to highlight it and click Properties Button
• Or, click the line and double-click again
• Or, Key F4

3. Set the properties:

Here is the list of the properties.

Select
Page Number	The selected page number
Open it	Display the PDF Page in the default viewer
Original Width/Height	The size of the selected PDF Page
Position (Left, Right, Width, Height)	The X and Y coordinate of the box to define the position of the inserted PDF Page.
Scale Width	The percentage of actual PDF Page width inside PDF to the original PDF Page width
Scale Height	The percentage of actual PDF Page height inside PDF to the original PDF Page height
Lock aspect ratio	The ratio of width and height will be kept as you change the size of the inserted PDF Page.
Relative to Original Size	The original width and height will be used.
Rotate	The rotation degree from 3 clock relative to the inserted PDF Page center.
Order	It will show on the Foreground or Background of the PDF document.
Action: Add Link, Submit, JavaScript and more ...	See PDF Actions
Frame Line (pt)	The thickness of the frame line around the inserted PDF Page.
Line Color	The color for the frame line.
Line Dashed	There are 8 Dashed Styles: Solid, Round Dot, Square Dot, Dash, Dash Dot, Long Dash, Long Dash Dot, Long Dash Dot Dot
Whiteout (Fill Color)	The background color of the frame, If set, it will be opaque. It can be used to cover the original text.

4. Screenshot:

Batch (DOS) Command Support:
You can start a batch job in Windows by issuing the execution command directly from the MS-DOS command prompt window without opening the PDFill GUI.
(It is only available for the registered user of PDFill PDF Editor)
